Description
SPECS
- Size – 140x140x25 mm
- Mounting hole spacing – 124,5×124,5 mm
- Connector & pin-configuration – 4-pin PWM
- Cable length – 2cm + 30cm NA-EC1 extension cable
- Bearing – SSO2
- Frame technology – AAO (Advanced Acoustic Optimization)
- Rotational speed (+/- 10%) – 1500 RPM
- Min. rotational speed @ 20% PWM (+/-20%) – 300 RPM
- Airflow – 140,2 m³/h
- Acoustical noise – 24,6 dB(A)
- Static pressure – 2,08 mm H₂O
- Input power (typical) – 1,19 W
- Input power (max.) – 1,56 W
- Input current (typical) – 0,1 A
- Max. input current – 0,13 A
- Operating voltage – 12 V
- MTTF > 150.000 h
