ASRock TRX50 WS

Original price was: 849,00 €.Current price is: 749,00 €.

SKU: 002-4940

Categories: AMD Motherboards, Motherboards

Brand: ASRock

Description

Feature	Description
Unique Feature	Superb Productivity: PCIe Gen5 (Graphics, M.2), Quad Channel DDR5 Rock-Solid Durability: Ultra Low-Loss PCB, 18+3+3 Power Phase, 110A SPS, Pre-Installed I/O Shield, 20K Black Caps Ultrafast Connectivity: 10G LAN, 2.5G LAN, Wi-Fi 6E EZ Update: BIOS Flashback, Auto Driver Installer
CPU Support	AMD Ryzen™ Threadripper™ PRO 9000/7000 WX-Series & 9000/7000 Series, Socket sTR5
Chipset	AMD TRX50
Memory	Quad Channel DDR5, 4x DDR5 DIMM Slots, Supports ECC RDIMM up to 7600+ (OC), Max 1TB
BIOS	256Mb AMI UEFI Legal BIOS
Audio	7.1 CH HD Audio (Realtek ALC1220), Nahimic Audio
LAN	10G LAN (Marvell AQC113), 2.5G LAN (RTL8125BG), Wake-on-LAN, PXE, Bandwidth Control, Optimized Profiles
Wireless	Wi-Fi 6E, Dual-Band 2×2, Bluetooth 5.2
Expansion Slots	3x PCIe 5.0 x16, 2x PCIe 4.0 x16 (x4 & x8), M.2 Key E (Wi-Fi)
Storage	CPU: 1x M.2 Gen5x4, 1x MCIO Gen5x4, 2x SlimSAS Gen4x4 or SATA Chipset: 1x M.2 Gen4x4, 4x SATA 6Gb/s
RAID	RAID 0/1/10 for SATA & NVMe (requires expansion card for RAID 10)
USB Ports	Rear: 1x USB 3.2 Gen2x2 Type-C, 4x USB 3.2 Gen2 Type-A, 1x USB 3.2 Gen2 Type-C, 2x USB 3.2 Gen1 Front: 1x USB 3.2 Gen2 Type-C, 2x USB 3.2 Gen1, 4x USB 2.0
Connectors	Thermistors, SPI TPM, COM, Intrusion Header, ARGB, Fan Headers, ATX & PCIe Power, Debug LED, Audio, Thunderbolt, etc.
Rear I/O	Wi-Fi Antennas, SPDIF Out, USB Ports, Dual LAN, Clear CMOS, BIOS Flashback, Audio Jacks
Software	ASRock A-Tuning, Dragon LAN, Polychrome SYNC
UEFI	Full HD UEFI, Instant Flash, Auto Driver Installer
Accessories	User Manual, SATA Cables, Antennas, Thermistors, PSU Cable, M.2 Screws & Standoffs
Form Factor	EATX, 12-layer PCB, 30.5 x 27.7 cm
Operating System	Windows 11 64-bit
Certifications	FCC, CE, ErP/EuP Ready
