Asus TUF GAMING B760M-PLUS WiFi II DDR5
245,00 €
In stock
SKU: 002-4970
Categories: Intel Motherboards, Motherboards
Brand: Asus
Description
| Feature | Specification |
|---|---|
| Model | TUF GAMING B760M-PLUS WIFI II |
| CPU | Supports Intel® Core™ 14th, 13th & 12th Gen, Pentium® Gold, and Celeron® Processors (LGA1700), Intel® Turbo Boost Technology 2.0 & 3.0 |
| Chipset | Intel® B760 |
| Memory | 4 x DIMM slots, Max. 192GB, DDR5 7800+(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600/5400/5200/5000/4800MHz, Dual Channel, Supports XMP & OptiMem II |
| Graphics | 1 x DisplayPort 1.4 (4K@60Hz), 1 x HDMI™ 2.1 (4K@60Hz) |
| Expansion Slots | 1 x PCIe 5.0 x16 (CPU) 1 x PCIe 4.0 x4 (Chipset) 1 x PCIe 3.0 x1 (Chipset) |
| Storage | 3 x M.2 slots (PCIe 4.0 x4/x2) 4 x SATA 6Gb/s Supports Intel® Rapid Storage Technology (RAID 0/1/5/10) |
| Ethernet | 1 x Realtek 2.5Gb Ethernet, TUF LANGuard |
| Wireless & Bluetooth | Wi-Fi 6E (802.11ax), 2×2 MU-MIMO, Bluetooth v5.3 |
| USB (Rear) | 1 x USB 20Gbps Type-C 1 x USB 10Gbps Type-A 2 x USB 5Gbps Type-A 4 x USB 2.0 Type-A |
| USB (Front) | 1 x USB 10Gbps Type-C 2 x USB 5Gbps ports 5 x USB 2.0 ports |
| Audio | Realtek 7.1 Surround Sound HD Audio CODEC, Optical S/PDIF out, Premium capacitors, Dedicated PCB layers |
| Back Panel I/O | 1 x USB 20Gbps Type-C 1 x USB 10Gbps Type-A 2 x USB 5Gbps Type-A 4 x USB 2.0 Type-A 1 x DisplayPort 1 x HDMI™ 1 x Wi-Fi Module 1 x Realtek 2.5Gb Ethernet 5 x Audio jacks 1 x Optical S/PDIF out |
| Internal I/O Connectors | 1 x 24-pin ATX Power Connector 2 x 8-pin +12V Power Connectors 3 x M.2 slots 4 x SATA 6Gb/s 1 x USB 10Gbps Type-C 2 x USB 5Gbps ports 5 x USB 2.0 ports 3 x Addressable Gen 2 headers 1 x Clear CMOS header 1 x Front Panel Audio header (AAFP) 1 x Thunderbolt™ (USB4®) header 1 x 20-3 pin System Panel header with Chassis intrude function |
| Cooling & Fan Headers | 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x 4-pin AIO Pump header 3 x 4-pin Chassis Fan headers |
| BIOS | 128 Mb Flash ROM, UEFI AMI BIOS |
| Special Features | ASUS TUF Protection (DIGI+ VRM, ESD Guards, TUF LANGuard, Overvoltage Protection, SafeSlot Core+, Stainless-Steel Back I/O) ASUS Q-Design (M.2 Q-Latch, PCIe Slot Q-Release, Q-Antenna, Q-DIMM, Q-LED) ASUS Thermal Solution (M.2 heatsinks, VRM heatsink) ASUS EZ DIY (CPU Socket lever protector, Pre-mounted I/O shield, SafeDIMM) Aura Sync (Addressable Gen 2 headers) |
| Software Features | ASUS Armoury Crate (AURA Creator, AURA Sync, Fan Xpert 2+, Power Saving) AI Suite 3 (Digi+ VRM, PC Cleaner) TUF GAMING CPU-Z DTS Audio Processing MyASUS Norton 360 for Gamers (60 Days Free Trial) WinRAR (40 Days Free Trial) |
| Operating System | Windows® 11, Windows® 10 64-bit |
| Accessories | 2 x SATA 6Gb/s cables 1 x ASUS Q-Antenna 1 x M.2 Rubber Package 1 x TUF Gaming sticker 2 x Screw packages for M.2 SSD 1 x TUF Certification card 1 x User Guide |
| Form Factor | Micro-ATX, 9.6 inch x 9.6 inch (24.4 cm x 24.4 cm) |
